SPECIFICATIONS
390 DC Micro Motor 6V 12V 24V High Speed 4200rpm 9426rpm 18900rpm Motors Reversed Strong Magnetic Electric DIY Model Fan RP390
Brand Name: HYSMOTOR
Certification: CCC
Certification: ROHS
Origin: Mainland China
Commutation: Brush
Type: Micro Motor
Protect Feature: Drip-proof
Construction: Permanent Magnet
Usage: BoAt
Usage: car
Usage: Electric Bicycle
Usage: Fan
Usage: Home Appliance
Efficiency: IE 1
Model Number: 390 High Speed Motor
Output shaft: 2.3 MM
Shaft length: 11.6 MM (9MM without steps)
Screw hole: 2.5 MM
Hole distance: 16 MM
Height: 47 MM (excluding front and rear bearing sleeves)
Motor outer diameter: 27.5 MM
Voltage:DC 6 V Speed: 4200 RPM
Voltage: DC 12 V Speed: 9426 RPM
Voltage: DC 24 V Speed: 18900 RPM
The rated voltage is DC12V, the sound is soft, but powerful. Suitable for vacuum cleaners, electric drills, micro-engraving machines, DIY enthusiast welfare motors, 6V-12V is also suitable for use in reducers. The motor can use the highest voltage 24V, the sound is very smooth, and the torque is greater
